MP3000-AR is an advanced electric wire arc thermal spray system engineered for high-productivity applications that require repeatable metallic coatings. The system combines a high-power 360GS power supply, PPC process console, coordinated wire feeding, compressed-air supply and dedicated wire arc spray guns in a modular production platform.
MP3000-AR is an advanced electric wire arc thermal spray system engineered for high-productivity applications that require repeatable metallic coatings. The system combines a high-power 360GS power supply, PPC process console, coordinated wire feeding, compressed-air supply and dedicated wire arc spray guns in a modular production platform.
The system is intended for wear protection, restoration of component dimensions and corrosion protection. Typical applications include industrial rollers, automotive exhaust components, aviation and aerospace parts, hydroelectric turbine components, aluminum extrusion mills and tube-mill weld seams.
A high power capacity of 400 A enables fast processing of both hard and soft wires. With soft wires, coating rates of up to 32 kg/h are possible. The gun head is designed to provide low-turbulence, near-laminar air flow for high deposition rates and dense, low-oxide coatings, while voltage is measured directly at the gun to support repeatable process results.
MP3000-AR uses a modular architecture that combines the power supply, process console, wire-feed system, spray gun and compressed-air circuit. The final arrangement can be configured for machine-mounted automated operation or hand-held spraying, depending on the selected gun model and production requirements.
The 360GS power supply provides the electrical output required for wire arc spraying over a 15–38 VDC output range and 20–420 A output current range at 100% duty cycle. The PPC console manages process operation and works with the gun and wire-feed system to maintain stable spraying conditions.
Compressed air supplied to the console is specified at 2.4–4.2 bar with a flow range of 58–105 m³/h. MP3000-AR uses PLC technology for automation functions and diagnostic tests that can be interpreted directly by the operator.
A key MP3000-AR function is the load-sharing wire-feed method. The gun pull motor acts as the master feed motor, while the console motor automatically provides additional push force when required. This coordinated push-pull action stabilizes wire feed and permits wire conduit lengths up to 15 m.
The wire feed and clamping system uses an adjustable air-actuated clamp to improve feeding reliability across hard, soft and cored wire types. Fixed-position gun contact tips and a quick-release wire connector support repeatable operation and fast feedstock changeover.
The PPG is the CE-conformant machine-mount push-pull spray gun for MP3000-AR. It is designed for mounting on a robot or other gun-manipulation equipment where precise, repeatable motion is required. The gun uses low-turbulence, near-laminar atomizing-air flow and measures arc voltage at the gun to support stable coating results.
The PPGH is the hand-held MP3000-AR gun variant. An optional handle can provide integrated system-wide emergency stop and wire-speed control at the gun. The source data sheet notes that this handle configuration is not CE-conformant and is not offered in CE-conforming countries.
MP3000-AR can be configured with a range of optional hardware, cables, air caps and gun extensions to adapt the system to different wire materials, spray patterns and component geometries.
Factory-equipped systems are configured for 1.6 mm hard wire. Optional hardware is available for the following wire configurations:
Depending on the selected soft wire, console or gun drive rollers may also require replacement with the appropriate configuration.
Fine Spray Air Cap – standard configuration for smooth coating surfaces.
Fan Air Cap – designed for large and wide surface areas.
High Velocity Air Cap – produces a narrower spray pattern.
High Profile Air Cap – intended for rougher surface finishes.
Focused Air Cap – narrow spray pattern with higher deposit efficiency.
PPGT-190 extension module: 305 mm (1 ft), 90° spray angle.
PPGT-290 extension module: 610 mm (2 ft), 90° spray angle.
Power, control, interconnecting extension, air-supply and wire-feed cables are available in various lengths.
Optional conversion kit is available for wire basket spools.
MP3000-AR is intended for industrial electric wire arc spraying where rapid metallic coating deposition, repeatable wire feeding and flexible automation are required. The system is used for wear protection, restoration of worn dimensions and corrosion-protection coatings.
MP3000-AR can be used on industrial rollers for printing and textile production, paper and pulp processing, embossing and steel manufacturing. The high deposition capability is suited to production and refurbishment tasks where repeatable metallic build-up is required.
Typical automotive applications include mufflers and exhaust-pipe seam welds, where wire arc spray can provide metallic surface protection along production weld areas.
MP3000-AR is specified for aviation and aerospace components requiring bond coatings and machinable restoration coatings. The machine-mount PPG gun can be integrated with automated manipulation equipment for repeatable processing.
Hydroelectric turbine parts are listed among MP3000-AR applications for power-generation equipment, including tasks that require protective or restorative metallic coatings.
MP3000-AR can be used in aluminum extrusion mill applications where industrial components require rapid, repeatable wire-deposited coatings.
Tube mill weld seams are another production application identified for MP3000-AR, taking advantage of continuous wire feeding and high-rate coating deposition.
The PPG machine-mount gun is designed for installation on robots or other gun manipulators. Combined with the MP3000-AR load-sharing wire-feed control and PLC-based console, this configuration supports automated coating production where consistent gun motion and repeatable wire delivery are required.
MP3000-AR is an electric wire arc thermal spray system designed for high-productivity industrial coating applications.
The listed configurations support 1.6 mm and 2.0 mm hard wires, and 1.6 mm, 2.0 mm and 2.3 mm soft wires. Optional hardware is used for selected wire configurations.
With soft wires, the MP3000-AR product data sheet states coating rates of up to 32 kg/h.
Yes. The PPG machine-mount gun is designed for installation on robots and other gun-manipulation equipment.
The MP3000-AR load-sharing push-pull feed system alloAR wire conduit cable lengths up to 15 m.
Two gun models are listed: the PPG machine-mount gun and the PPGH hand-held gun.
|
Thermal spray process
|
Electric wire arc thermal spray |
|
Power supply
|
360GS |
|
System control
|
PLC-based PPC console with diagnostics |
|
Output voltage range
|
15–38 VDC, 100% duty cycle |
|
Input voltage
|
3-phase 460 V, 60 Hz; 230 V, 60 Hz; 380–400 V, 50/60 Hz (CE); 575 V, 60 Hz (CSA) |
|
Output current
|
20–420 A, 100% duty cycle |
|
Input current
|
27.6 A (460 V); 51.0 A (230 V); 32.1 A (400 V CE); 24.4 A (575 V CSA) |
|
PPC console air pressure
|
2.4–4.2 bar |
|
Maximum ambient temperature
|
40 °C |
|
PPC console air flow
|
58–105 m³/h |
|
Power supply weight
|
49.4 kg |
|
PPC console weight
|
109 kg |
|
Hard-wire sizes
|
1.6 mm; 2.0 mm |
|
Gun models
|
PPG machine-mount with tool post; PPGH hand-held |
|
Soft-wire sizes
|
1.6 mm; 2.0 mm; 2.3 mm |
|
PPG gun weight
|
3.1 kg |
|
PPGH gun weight
|
4.1 kg |
|
Maximum stated coating rate
|
Up to 32 kg/h with soft wires |
|
Maximum wire conduit length
|
Up to 15 m |
|
Arc cart with interface box weight
|
129.3 kg |
|
Overall cart dimensions
|
1353 × 635 × 1627 mm |
